APEX ABR090-010-S2-P2

Category: Tags: , ,

Description

APEX ABR090-010-S2-P2

ABR090-010-S2-P2/MITSUBISHI HG-KN73

ABR-Series

Output torque
T2N : 9 Nm – 2000 Nm
Ratios:
1-stage :3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 / 12 / 14 / 16 / 20
2-stage :12 / 16 / 15 / 20 / 25 / 28 / 30 / 32 / 35 / 40 / 45 / 48 / 50 / 60 / 64 / 70 / 80 / 90 / 100 / 120 / 140 / 160 / 180 / 200
*Only ABR042 2-stage offers 15,20 option
Low backlash
1-stage : ≦2arcmin / ≦4arcmin / ≦6arcmin
2-stage : ≦4arcmin / ≦7arcmin / ≦9arcmin
High efficiency
1-stage : ≧ 95%
2-stage : ≧ 92%
Easy mount
Low noise

Specifications

Primary brand
APEX Dynamics
Main function
Gearbox (Planetary; Angled)
Product series / family name
AB / ABR Series
Sub-range name
ABR (90degree Angled)
Sound / Noise level
68 dB
Efficiency
95%
Degree of protection
IP65
Net Width (mm)
(Flange) 115 mm
Material
Stainless steel
Maximum radial load
6700 N
Maximum axial load
3350 N
Technology used in component
1-stage reduction
Planetary reduction
Synthetic lubrication oil
Mechanical durability
20 000 hours
Mounting mode
All directions
Nominal torque
325 N.m
Nominal torque
239.707698515025 ft.lbf
Maximum torque
(Emergency stop) 975 N.m
Gear ratio
1/10
Backlash
6arcmin
Moment of inertia
0.000684 kg.m²
Torsional rigidity
25Nm/arcmin
Net weight
13 kg
Shape
90degree Angled
Output Shaft with Key
Triple split collet Input
Minimum temperature
-10 °C
Maximum temperature
+90 °C
Rotational speed
4000 rpm
(Maximum) 8000 rpm
