ORIENTAL NETC01-CC

Description

ORIENTAL NETC01-CC

NETC01-CC, Network Gateway (CC-Link Compatible)

Network gateways are a device that converts from the host communication protocol to Oriental Motor’s own RS-485 communication protocol. By using this network gateway, our RS-485 compatible products can be controlled under host communication environment.

• Includes: Communication Cable, Power Supply Connector

Available to Ship1	Contact your local sales office. This Item cannot be cancelled or returned.
Return Policy	This product cannot be cancelled or returned once the order has been processed.
Network	CC-Link
Power Supply	24 VDC ±10% 0.2A
Communication Protocol	CC-Link Ver. 1.10
Baud Rate	156kbps/625kbps/2.5Mbps/5Mbps/10Mbps
Station Type	Remote device station
Number of Occupied Stations	4
Max. # of Connectable Units	Number of units which meet the following requirements: (1 x a) + (2 x b) + (3 x c) + (4 x d) ≤ 64 a: # of units w/ 1 occupied station b: # of units w/ 2 occupied stations c: # of units w/ 3 occupied stations d: # of units with 4 occupied stations (16 x A) + (54 x B) + (88 x C) ≤ 2304 A: # of remote I/O station units (64 max.) B: # of remote device station units (42 max.) # of local stations (26 max.)
Insulation Resistance	100 MΩ or more when a 500 VDC megger is applied between the following locations: FG Terminal – Power Supply Terminal
Dielectric Strength	Sufficient to withstand 500 VAC, 50 or 60 Hz applied between the following places for 1 minute: FG Terminal – Power Supply Terminal
Ambient Temperature	0 ~ +40ºC (+32 ~ 104ºF)(non-freezing)
Ambient Humidity	85% or less (Non-Condensing)
Altitude	Up to 1000 m (3300 ft.) above sea level
Operating Environment	No corrosive gases, dust, water or oil.
