Description
SMC MHZL2-16D
Xy lanh kẹp SMC MHZL2-MHL2-MHY2-MHC2-10D-16D-20D-25D-32D-40D là 4 series MHZL2-MHL2-MHY2-MHC2 với các kích thước Bore size khác nhau 10, 20, 25, 32, 40.
Parallel Type Air Gripper, Long Stroke MHZL2 Series (MHZL2-16D)
Configured Specifications
| Type | [Main Body] Main body | Gripping Methods | Pinch, Parallel Type / Open, Parallel Type |
|---|---|---|---|
| Number of Fingers | 2 pcs. | Main Body Shape | Square Shape |
| Operation Method | Double Acting Type | Dimensions when open(mm) | 26.9 |
| Dimensions when closed(mm) | 14.9 | Gripping Force (when 0.5Mpa at opening)(N) | 45 |
| Gripping Force (when 0.5Mpa at closing)(N) | 34 | Environment, Applications | Standard |
| Additional Functions | With Linear Guide / High Accuracy | Stroke Adjustment Mechanism | Not Provided |
| Operating Pressure Range(MPa) | 0.1～0.7 | Cylinder internal diameter(mm) | 16 |
| Finger position / Options | Basic type | Body options | Basic type |
| Auto switch | Without auto switch | Number of switches | None |
| Lead wire length | None | Made to order specifications | None |
| Connector type for gripper opening/closing | None | Dust cover materials | – |
Quý khách hàng có thể đặt hàng theo những mã chi tiết sau:
MHZL2-10D
MHZL2-16D
MHZL2-20D
MHZL2-25D
MHC2-10D
MHC2-16D
MHC2-20D
MHC2-25D
MHY2-10D
MHY2-16D
MHY2-20D
MHY2-25D
MHL2-10D
MHL2-16D
MHL2-20D
MHL2-25D
MHZL2-10S
MHZL2-16S
MHZL2-20S
MHZL2-25S
MHZL2-10D1/D2/D3
MHZL2-16D1/D2/D3
MHZL2-20D1/D2/D3
MHZL2-25D1/D2/D3
