SOLBERG CSL-848-151HCB (reference VFY034A)

Description

SOLBERG CSL-848-151HCB (reference VFY034A)

Fuji:  VFY034A

 Solberg Part Number

CSL-848-151HCB

  • CSL Series, Inlet Vacuum filter
  • See attached Datasheet for reference
  • 1.5” BSPP Connections
  • Includes 2 micron paper filter element (99+% efficient)
  • Carbon steel construction with black powder coat paint

Fuji VFY032A-E

Solberg Standard Part Number

848

  • 2 micron paper filter element (99+% efficient)
  • See the attached datasheet for reference

Vacuum Filter, Paper Element CSL-848-151HCB (reference VFY034A)

Product Description

A dust and particle separator for collecting with Fuji ring blows. A cylindrical element in a sealed rigid case for added protection to filter particles and prevent flow into the interior.

[Features]
· Extremely low ventilation resistance.
· Superior airtightness.
· Easy maintenance and inspection, easy replacement of element with bare hands

Configured Specifications

Insulating material area(m2) 0.42 Specifications
Piping Opening Diameter, Nominal Designation of Thread Rp1 1/2 (Parallel Female Screw)

Features

3/8″ – 4″ Connections:

  • Seamless drawn housings
  • O‐ring seal
  • Corrosive resistant gray powder coat carbon steel
  • Stainless steel torsion clips

3″ – 12″ Connections:

  • Heavy duty T bolts for easy maintenance
  • Corrosive resistant black powder coat carbon steel
  • O-ring stays in place with unique U-channel groove
  • Inlet & outlet 1/4” gauge taps

Technical Specifications

  • Vacuum Rating: medium vacuum service
  • Temp (continuous): min ‐15°F (‐26°C) max 220°F (104°C)
  • Filter change out differential: 15-20″H2O (37‐50 mbar) over initial Δ P
  • Polyester: 99%+ removal efficiency standard to 5 micron
  • Paper: 99%+ removal efficiency standard to 2 micron

Options

All Sizes:

  • Vacuum gauge
  • Straight-through configurations
  • Various filter media
  • Various finishes and connection styles
  • Stainless steel



3/8″ – 4″ Connections: ​​

  • Stainless steel (select models)
  • ISO Flange (contact factory for specs, sizes & availability)
  • Mounting housing bands
  • Alternative top‐to‐canister fastening system for low pressure or pulsating systems



3″ – 4″ Connections: ​

  • Differential inlet/outlet gauge taps
  • Integrated baffle (3″ – 4″ connections)
  • Support brackets

3″ – 12″ Connections: ​

  • ISO Flange (contact factory for specs, sizes & availability)
  • Flange faces free of paint
  • Internal surfaces free of paint
  • Lifting lugs
  • Brackets for optional support legs
  • Nameplate bracket

Applications

  • Vacuum Packaging
  • Vacuum Lifters
  • Blowers-Side Channel
  • Soil Venting/Remediation
  • Factory Automation
  • Leak Detection
  • Woodworking
  • Blowers-Side Channel
  • Ash Handling
  • Cement
  • Compressor-Piston
  • Compressor-Screw
