VEGA VEGAPULS 62 PS62.UFBAE2HDNAX
Cảm biến đo mức VEGA VEGAPULS 62 PS62.UFBAE2HDNAX
VEGAPULS 62 Radar sensor | VEGAPULS 62 Cảm biến mức radar
1. Mô tả VEGAPULS 62 Radar sensor | VEGAPULS 62 Cảm biến radar
The Vegapuls 62 is a universally implementable radar sensor for continuous level measurement of liquids. It is suitable for level measurement in storage containers, reactors and process vessels, even under difficult process conditions. With its various antenna versions and materials, VEGAPULS 62 is the optimal solution for almost all applications and processes. Its wide temperature and pressure range makes project planning simple.
2. Thông số kỹ thuật VEGAPULS 62 Radar sensor | VEGAPULS 62 Cảm biến radar
- Measuring range up to 35 m (114.8 ft)
- Deviation ±2 mm
- Process fitting Thread from G1½; 1½ NPT; flanges from DN 40, 1½”
- Process pressure -1 … +160 bar/-100 … +16000 kPa (-14.5 … +2320 psig)
- Process temperature -196 … +450 °C (-321 … +842 °F)
- Ambient, storage and transport temperature -40 … +80 °C (-40 … +176 °F)
- Operating voltage 9.6 … 36 V DC
- SIL qualification Optionally up to SIL2
3. Ứng dụng VEGAPULS 62 Radar sensor | VEGAPULS 62 Cảm biến radar
The universal genius for level measurement of liquids under difficult conditions
The level transmitter VEGAPULS 62 is used mainly in the chemical and petrochemical industry as well as in environmental engineering and recycling. Difficult process conditions such as extreme temperature or pressure or even vacuum are no problem at all for the level transmitter VEGAPULS 62: The instrument reliably detects the level in storage tanks and process vessels. Thanks to radar technology, the level transmitter detects liquids contactlessly and delivers continuous, highly accurate readings.
Radar sensor for continuous level measurement of liquids
In extreme temperatures and pressures
VEGAPULS 62
Radar sensor for continuous level measurement of liquids
In extreme temperatures and pressures
Application area
Your benefit
- Exact measuring results independent of pressure, temperature, gas and steam
- High plant availability, because wear and maintenance-free
- Maintenance-free operation through non-contact measuring principle
Technical specifications
Measuring range – Distance : 35 m
Process temperature : -196 … 450 °C
Process pressure : -1 … 160 bar
Accuracy : ± 2 mm
Version :
- for separate horn antenna
- with ½” standpipe
- with horn antenna ø 40 mm
- with horn antenna ø 48 mm
- with horn antenna ø 75 mm
- with horn antenna ø 95 mm
- with parabolic antenna ø 245 mm
Materials, wetted parts
- 316L
- Alloy C22 (2.4602)
- 1.4848
- Alloy 400 (2.4360)
- Tantalum
Threaded connection : G1½, 1½ NPT
Flange connection : ≥ DN50, ≥ 2″
Seal material
- FKM
- FFKM
- graphit and ceramic
Housing material
- Plastic
- Aluminium
- Stainless steel (precision casting)
- Stainless steel (electropolished)
Protection rating
- IP 66/IP 68 (0.2 bar)
- IP 66/IP 67
- IP 66/IP 68 (1 bar)
Output
- Profibus PA
- Foundation Fieldbus
- 4 … 20 mA/HART – two-wire
- Modbus
- 4 … 20 mA/HART – four-wire
Ambient temperature : -40 … 80 °C
